1000m Multi-Function Truck-Mounted Drilling Rig

Feature

  • The drilling rig is equipped with a high-power hydraulic motor and hydraulic drill arm,which can carry out DTH hammer drilling,and is equipped with a large-flow mud pump,which can realize mud drilling.

  • The mud pump and air compressor are all on the same chassis,and equipped with a foam pump,which is convenient and efficient,and its overall performance is higher than other types of drilling rigs.


Contact Now E-Mail Telephone WhatsApp
Product Details

The drilling rig is equipped with a high-power hydraulic motor and hydraulic drill arm,which can carry out DTH hammer drilling,and is equipped with a large-flow mud pump,which can realize mud drilling.




Product Parameters

Name

Model

Parameter

Car Chassis

Special Chassis

Sinotruk SINOTRUK 6X4 ,290HP

Rig


Tower bearing capacity: 50T

 Two hydraulic cylinders

Oil cylinder rig height: 6M

Lift Feed

Cylinder


Feeding force: 15T

Lifting force: 30T

Hydraulic

Outriggers


Four hydraulic outriggers

Drilling

Power


Chassis power



Winch


Lifting force 2T

Power Head


Torque:10000NM

Speed: 0-90 RPM

Foam Pump


Flow 42L/MIN Pressure: 4MPA Improve the efficiency of drilling cuttings up and down,and cool and lubricate the impactor

Console


Integrated operating table Lifting boring

tower, outrigger cylinder, lifting, power

head and other system pressure gauges, etc.

Air Compressor


Pressure:3.5Mpa

Flow: 35m³/min

Mud Pump


Flow: 1100L/M

Pressure: 5Mpa

Drilling depth


1000M

Opening diameter


500MM

Dimensions


12000×2550×3500MM



Overall weight


26000KG





Company:

CompanyCompany


We has been for a long term focus on "drilling industry" solutions and research. The company recruits mining industry elite, grasping the core technology with a number of R & D patents. JuSheng people always insist on "change" mode, making bold innovation. It is being a top manufacturing company with a full system of research, manufacture and marketing.



The company lies in rencheng city shandong jining province ,with workshop space of 1000 m2 and more than 30 employees.


We have workshops for material processing, Semi-automatic welding equipment, cutting production line, drill and polish area. We have passed ISO 9001 certificate and won National High-Tech Enterprise, which helped us establish as a well-known and conscientious enterprise.





Packaging & Shipping:

Packaging

Packaging






Exhibition:


Exhibition


Exhibition


Exhibition




FAQ:

1.Do you test all your goods before delivery?

Ans.:Yes,wehave100%test before delivery.And we will attach our inspect report for every machine



2.Do you Preferred provide wear parts for transacted clients?

Ans.:Yes,we have records for your clients,and will prefer providing accessories to clients



3.How do you make our business long-term and good relationship?

Ans.:

1.We keep good quality and competitive price to ensure our customers benefits;

2. We respect every customer as our friend and we sincerely do business and make friends with them,no matter where they come from
