Feature
1. All drilling rigs are multifunctional, it can be used with air compressor, mud pump, even we can just use the dry hydraulic drilling method.
2.The drilling rigs are not only designed for water drilling. They can be used in all conditions based on pore-forming purpose.
Product
Product Parameters：
Name | Model | Parameter |
Car Chassis | Special Chassis | Sinotruk SINOTRUK 6X4 ,290HP |
Rig | Tower bearing capacity: 35t Two hydraulic cylinders Oil cylinder rig height: 6M | |
Lift Feed Cylinder | Feeding force: 12T Lifting force: 25T | |
Hydraulic Outriggers | Four hydraulic outriggers | |
Drilling Power | Equipped With Hydraulic Triangular Valve To Avoid Oil Leakage Of Hydraulic Valve | |
Winch | Lifting force 1T | |
Power Head | Torque:9500NM Speed: 0-90 RPM | |
Foam Pump | Flow 42L/MIN Pressure: 4MPA Improve the efficiency of drilling cuttings up and down, and cool and lubricate the impactor | |
Console | Integrated operating table Lifting boring tower, outrigger cylinder, lifting, power head and other system pressure gauges, etc. | |
Air Compressor | Pressure: 2.4Mpa Flow: 29m³/min | |
Mud Pump | Flow: 900 L/M Pressure: 2.5Mpa | |
Drilling depth | 500M | |
Opening diameter | 500MM | |
Dimensions | 12000×2550×3500MM
| |
Overall weight | 26000KG |
Company:
JS Drill (Zoucheng Jusheng Mining Machinery Co., Ltd) is an integrated mining and engineering machinery manufacturer and trader that specialized in producing, processing and sale of water well drill machine, air compressor, DTH hammer, drill bits and drill rods.
We have workshops for material processing, Semi-automatic welding equipment, cutting production line, drill and polish area. We have passed ISO 9001 certificate and won National High-Tech Enterprise, which helped us establish as a well-known and conscientious enterprise. Our bolts, air compressor and water well drilling rigs passed CE certificate. Over the past decades of production and development, we have set up our own management and after-sales service system.
Exhibition:
Customer Visit :
FAQ:
Q: Are you factory?
A: Our drilling rig factory has more than fifteen years of manufacturing experience, we can provide OEM and ODM services; our drilling tool factory has 25 years of manufacturing experience, mainly supplying DTH drilling tools and top hammer drilling tools.
Q: What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q: What is your terms of delivery?
A: EXW, FOB, CFR, CIF.We have a very good cooperation in shipping logistics, and the price is low.Not only our product price is advantageous, but also our logistics price.
Q: Can you do OEM for me?
A: Yes, JS can provide OEM service for customers
